Orifice Flanges ASME B16.36
Orifice Flanges is an indispensable part in pipeline construction. It is formed by high-temperature and high-pressure forging of raw material metal round bar or plate. Through heat treatment and tempering, it has higher performance of corrosion resistance, high-pressure resistance, high-temperature resistance and low-temperature impact resistance.
Carbon steel, low temperature pipeline steel, stainless steel, dual phase steel, nickel base alloy – Orifice Flanges
Cangzhou Enfei Pipe Equipment Co., Ltd. is an excellent Orifice Flanges manufacturer in China,The Orifice Flanges is a product formed by high-temperature and high-pressure forging of the raw material metal round bar or steel plate. Therefore, the Orifice Flanges has high requirements for raw materials.
Whether the raw materials are high-quality determines the quality of the Orifice Flanges products. Next, the Orifice Flanges performance is determined by the heat treatment process. The heat treatment temperature is generally between 700 and 1300 degrees Celsius. The heat treatment process determines the low-temperature impact resistance, high-temperature resistance, corrosion resistance Standard parameters such as welding performance and hardness.
As an excellent Orifice Flanges manufacturer, Cangzhou Enfei Pipe Equipment Co., Ltd. selects raw materials produced by the best factories in China, including Yongxing special steel, AVIC Shangda, Huaxin Lihua, qingtuo group, Laiwu Iron and steel, Valin Iron and steel, Taiyuan Iron and steel, Shanghai Baosteel, Baosteel and other China’s best steel groups.
The above raw material manufacturers have passed ABS and DNV GL, BV, LR, CCS, NKclass, KR, RINA and RS classification societies can issue EN10204 3.2 and EN10204 3.1 material list certificates. Cangzhou Enfei Pipe Equipment Co., Ltd. focuses on serving global customers.
Manufacturing standards include: ASME/ANSI B16.9, ASME/ANSI B16.47, ASME /ANSI B16.48, MSS SP44, ASA, API-605, AWWA, custom drawings DIN2527-DIN2673, EEMUA145 146 234, BS4504, BS1560, BS10, HG/T20592 HG/T20615, GB /T9115-GB/T9119, JIS B2220, JPI-7S-15, etc.
Orifice Flanges products produced by Cangzhou Enfei Pipe Equipment Co., Ltd. have a variety of materials to choose from, including:ASTM A105, ASTM A182 F11 CL1 F11 Cl2 F11 CL3 F12 CL1 F12 Cl2 F304 F304H F30L F317 F321 F347 F51 F53 F55 F60 ASTM A694 F42 F48 F50 F52 F56 F60 F65 F70, ASTM / ASME SB466 UNS NO.C70600 (Cu / NI-90 / 10), C71500 (Cu / ni-70 / 30), ASTM / ASME SB336, ASME SB564 / 160 / 163 / 472, UNS2200 (nickel200) UNS2201 (nickel201), UNS4400 (MONEL400), UNS8020 (alloy20 / 20 CB3), UNS8825 Inconel (825), UNS6600 (inconel600), UNS6601 (inconel200)601), UNS6625 (Inconel625), UNS10276 (Hastelloy C276), etc.
In the above Orifice Flanges production materials, our dual phase steel meets the requirements of A182 F53 / F55 PREN (% Cr + 3.3% Mo + 16% N) ≥ 40, F51 / F60 N = 0.14-0.2% and PREN (% Cr + 3.3% Mo + 16% N) ≥ 34, product pressure 75LB 150LB 300LB 400LB 600LB 900LB 1500LB 2500LB DIN Standard PN-2.5,6,10,16,25,40,50,64,110,150,250,320,400, and product specification 1/8-72 inch to meet customers’ various choices.
Due to the high standard, good material and many specifications of Orifice Flanges provided by our company, we are able to undertake many small, medium and large projects, coupled with our service attitude of resolutely considering for customers, which also makes our customers have a high rate of return.
The contracts signed and delivered come from Europe, Africa, Asia, South America, North America, etc., with a wide range of customer coverage, and have won the unanimous praise of customers. Our company also keeps refining its products to meet the new issues raised in the new era while the rapid development of the times.
Orifice Flanges Industrial Steel Flanges Test Certificates: Cangzhou Enfei Pipe Equipment Co., Ltd. offer its Products with Third Party Inspection also. The Inspection Agency can be nominated by clients or Dynamic Forge & Fittings can be arrange the TPI by World reputed Agencies like Bureau Veritas, ABS, NKClass,SGS and many other.
Orifice Flanges Specification
| Size | 1/2〞（DN15）to 60〞(DN1500) | |||||
| Class | 150LBS,300LBS,400LBS，600LBS,900LBS,1500LBS,2500LBS.
DIN Standard PN-2.5,6,10,16,25,40,50,64,110,150,250,320,400. |
|||||
| Flange Face Type | Amerrican Series:Flat face(FF),Raised Face(RF),Tongue(T),Groove(G),Female(F),Male(M),Ring Joints Face(RJ) | |||||
| Surface Treatment | Antirust Paint,Oil Black Paint,Yellow Transparent,Zinc Plated,Cold and Hot Dip Galvanized | |||||
| Manufacturing process | Cutting,Heat treatment,Die Forging/Free Forging,CNC Machining | |||||
| Manufacturing Standards | ANSI/ASME B16.5 Flanges,ANSI/ASME B16.47 Flanges,ANSI/ASME B16.36 Flanges，ANSI/ASME B16.48 Flanges ，MSS SP44 Flanges
ASA,API-605 Flanges,AWWA Flanges,Custom Drawings Flanges ，EEMUA145 146 234 Flanges，BS 10 Flanges，DIN Flanges，EN 1092-1 Flanges BS 4504 Flanges，JIS Standard Flanges |
|||||
| Material Grades： | ||||||
| Carbon Steel | ASTM A105/A105N, A350 LF1, LF2 CL1/CL2, LF3 CL1/CL2, A694 F42, F46, F48, F50, F52, F56, F60, F65, F70, A516.60, 65, 70
(Spectacle Blind Flange, Spacer Ring/Spade Flange), Steel RST37.2, C22.8 |
|||||
| Stainless Steel | ASTM A182 F202, F304/304L/304H, F316/316L, F316H, F316TI, F310, F321, F904L | |||||
| Duplex & Super Duplex Steel | ASTM / ASME A/SA 182 F44, F45, F51, F53, F55, F60, F61, 2205 (UNS No. S31803), 2507 (UNS No.S32750)，1.4462,1.4410，1.4547 | |||||
| Alloy Steel | ASTM A182 F1, F5, F9, F11, F22, F91 | |||||
| Copper Alloy Steel | UNS No. C10100, 10200, 10300, 10800, 12000, 12200, 70600, 71500, UNS No. C70600 (Cu -Ni- 90/10), C71500 (Cu -Ni- 70/30) | |||||
| Nickel Alloy | Nickel 200 (UNS No. N02200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500)
Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625) Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II). |
|||||
Orifice Flanges Tensile Properties Testing
